Target audience: Intermediate
Estimated reading time: 5'
Conventional distributed batch processing systems fall short in supporting applications like social media platforms, Internet of Things, or business-to-consumer online transactions. Fortunately, Apache Structured Streaming equips software developers with the necessary tools for large-scale, real-time stream processing.
This article delves into how the classic Extract-Transform-Load (ETL) pipeline is implemented within the realm of real-time streaming data.
What you will learn: How to implement real-time ETL using Spark Structured Streaming.
Table of contents
Notes:
- It's presumed that the reader has a basic understanding of the Apache Spark framework
- Environment Scala 2.12.11, Apache Spark 3.4.0, Spark streaming 3.4.0
- Error handling and comments in source code has been omitted for sake of clarity.
Introduction
Apache Spark
Apache Spark is an open-source distributed computing system designed for handling large-scale data processing [ref 1]. It leverages in-memory caching and refined query execution strategies to deliver rapid analytic responses, regardless of the data's size.
Spark streamlines the process by requiring only a single step: data is loaded into memory, operations are executed, and outcomes are written back, leading to significantly quicker execution. Additionally, Spark enhances efficiency in machine learning algorithms by caching data in memory, allowing for rapid repeated function calls on the same dataset.
Structured streaming
Apache Spark Structured Streaming is a stream processing framework that's both scalable and resilient to faults, built atop the Spark SQL engine. Its approach to streaming computation mirrors the batch processing model applied to static datasets. The Spark SQL engine manages the task of executing this process incrementally and perpetually, updating the outcomes as new streaming data flows in [ref 2].
In contrast with Spark's original streaming library that relied on RDDs, Structured Streaming facilitates processing based on event time, incorporates watermarking features, and utilizes the DataFrame API that is a part of Spark SQL.
Spark Streaming processes incoming data by splitting it into small batches, which are executed as Resilient Distributed Datasets (RDDs). On the other hand, Structured Streaming operates on a DataFrame linked to an infinite table, using an API that's fine-tuned for enhanced performance [ref 3].
Streaming components
In this section, we'll provide a concise overview of the essential elements of Spark Streaming that are employed in any Extract-Transform-Load (ETL) process.
Setup
To develop a structured streaming application, at least three Spark libraries, in the form of jar files, are essential: Core, SQL, and Streaming. The Maven pom.xml snippet provided below demonstrates how to set up these three libraries:
To develop a structured streaming application, at least three Spark libraries, in the form of jar files, are essential: Core, SQL, and Streaming. The Maven pom.xml snippet provided below demonstrates how to set up these three libraries:
<spark.version>3.4.0</spark.version>
<dependency> <groupId>org.apache.spark</groupId> <artifactId>spark-core_2.12</artifactId> <version>${spark.version}</version></dependency><dependency> <groupId>org.apache.spark</groupId> <artifactId>spark-sql_2.12</artifactId> <version>${spark.version}</version></dependency><dependency> <groupId>org.apache.spark</groupId> <artifactId>spark-streaming_2.12</artifactId> <version>${spark.version}</version></dependency>
Important note: The artifact for Spark structured streaming with input from Kafka is spark-streaming-kafka-0-10_2.12.
Our use case utilizes Spark's transformations and actions to construct an ETL (Extract, Transform, Load) pipeline.A transformation refers to any operation in Spark that yields a DataFrame or Dataset, and is executed in a lazy manner, meaning it's not computed immediately.An action, on the other hand, prompts a computation to deliver a result, thereby initiating the execution of all prior transformations in the sequence.
Transformation
The class STransform defined the data transformation of DataFrame (map function) using SQL, syntax.
<spark.version>3.4.0</spark.version>
<dependency>
<groupId>org.apache.spark</groupId>
<artifactId>spark-core_2.12</artifactId>
<version>${spark.version}</version>
</dependency>
<dependency>
<groupId>org.apache.spark</groupId>
<artifactId>spark-sql_2.12</artifactId>
<version>${spark.version}</version>
</dependency>
<dependency>
<groupId>org.apache.spark</groupId>
<artifactId>spark-streaming_2.12</artifactId>
<version>${spark.version}</version>
</dependency>
Important note: The artifact for Spark structured streaming with input from Kafka is spark-streaming-kafka-0-10_2.12.
Our use case utilizes Spark's transformations and actions to construct an ETL (Extract, Transform, Load) pipeline.
A transformation refers to any operation in Spark that yields a DataFrame or Dataset, and is executed in a lazy manner, meaning it's not computed immediately.
An action, on the other hand, prompts a computation to deliver a result, thereby initiating the execution of all prior transformations in the sequence.
Transformation
The class STransform defined the data transformation of DataFrame (map function) using SQL, syntax.
The class attributes are:- selectFields: List of fields to display
- whereConditions: WHERE conditions if not empty
- transformFunc: DataFrame transformation function DataFrame => DataFrame
- descriptor: Optional descriptor
The selects fields and whereConditions are concatenate for the SQL statement. There is no validation of the generated SQL query prior execution.
The class attributes are:
- selectFields: List of fields to display
- whereConditions: WHERE conditions if not empty
- transformFunc: DataFrame transformation function DataFrame => DataFrame
- descriptor: Optional descriptor
The selects fields and whereConditions are concatenate for the SQL statement. There is no validation of the generated SQL query prior execution.
TransformFunc = (DataFrame, String) => DataFrame
class STransform(
selectFields: Seq[String],
whereConditions: Seq[String],
transformFunc: TransformFunc,
descriptor: String = ""
){
def apply(df: DataFrame): DataFrame = transformFunc(df, queryStmt)
def queryStmt: String = {
val whereConditionStr = if (whereConditions.nonEmpty) s"WHERE ${whereConditions.mkString("AND ")}" else ""
s"SELECT ${selectFields.mkString(",")} FROM temptable $whereConditionStr"
}
}
Action
The class SAggregator wraps the group by operation with an aggregation function.
- groupByCol: Column used for grouping (groupBy)
- aggrCol: Column used by the aggregation function
- aggrFunc: Aggregation function that convert a Column into another Column
- aggrAliasName: Alias name for the aggregated values.
AggrFunc = Column => Column
class SAggregator(
groupByCol: Column,
aggrCol: Column,
aggrFunc: AggrFunc,
aggrAliasName: String
){
def apply(inputDF: DataFrame): DataFrame =
inputDF.groupBy(groupByCol).agg(aggrFunc(aggrCol).alias(aggrAliasName))
}
Streams wrapper
SparkStructStreams defines the generic wrapper trait for structured streaming with the minimum set of required attributes to describe any ETL-based pipeline.
Each specific ETL pipeline has to override the following variables:
- outputMode Mode for writer stream (i.e. Append, Update, ...)
- outputFormat Format used by the stream writer (json, console, csv, ...)
- outputColumn Name of the aggregated column
- isConsoleSink Flag to enabled Console sink for debugging purpose
- transform Optional transformation (input dataframe, SQL statement) => Output data frame
- aggregator Optional aggregator with groupBy (single column) and sql.functions._ aggregation function.
trait SparkStructStreams{
val outputMode: OutputMode
val outputFormat: String
val outputColumn: String
val isConsoleSink: Boolean
val transform: Option[STransform]
val aggregator: Option[SAggregator]
}ETL
Streaming pipeline
Our data pipeline implements the conceptual Extract-Transform-Load pattern.
The extraction consists of reading the data stream from HDFS in JSON format. The two fundamental types of data processing tasks in Apache Spark are transformations (map) and actions (reduce). They implements the transform section of the pipeline.
Finally the data stream is written into sink as CSV file, implementing the Load task.
Spark streaming ETL data pipeline
We wrap the streaming pipeline into a class, SparkStructStreaminFromFile inherited from SparkStructStreams to which we add the path of the source, folderPath and an implicit reference to the SparkSession.
As the transform and aggregation tasks rely on SQL statements, we need to extract the schema from the data source. The data source consists of JSON files so we infer the schema from the first record.
class SparkStructStreamsFromFile (
folderPath: String, // Absolute path for the source file
override val outputMode: OutputMode, // Mode for writer stream (i.e. Append, Update, ...)
override val outputFormat: String, // Format used by the stream writer (json, console, csv, ...)
override val outputColumn: String, // Name of the aggregated column
override val isConsoleSink: Boolean,
override val transform: Option[STransform], // Transformation (DataFrame, SQL) => DataFrame
override val aggregator: Option[SAggregator] // groupBy (single column) + sql.functions._
)(implicit sparkSession: SparkSession) extends SparkStructStreams {
// Extract schema from files
lazy val schema: StructType =
sparkSession.read.json(s"hdfs://${folderPath}").head().schema
def execute(): Unit = { // -------------------- EXTRACT ------------------------
// Step 1: Stream reader from a file 'folderPath'
val readDF: DataFrame = sparkSession
.readStream
.schema(schema)
.json(s"hdfs://$folderPath")
assert(readDF.isStreaming)
// ----------------- TRANSFORM ---------------------
// Step 2: Transform
val transformedDF: DataFrame = transform.map(_(readDF)).getOrElse(readDF)
// Step 3: Aggregator
val aggregatedDF = aggregator.map(_(transformedDF)).getOrElse(transformedDF)
// Step 4: Debugging to console
aggregatedDF.writeStream.outputMode(OutputMode.Complete()).format("console").start()
//-------------------- LOAD ---------------------------
// Step 5: Stream writer into a table
val query = aggregatedDF
.writeStream
.outputMode(OutputMode.Update())
.foreachBatch{ (batchDF: DataFrame, batchId: Long) => batchDF.persist()
batchDF.select(outputColumn)
.write
.mode(SaveMode.Overwrite)
.format(outputFormat)
.save(path = s"hdfs://output/$outputFormat") batchDF.unpersist()
}
// Step 6: Initiate streaming
.trigger(Trigger.ProcessingTime("4 seconds"))
.start()
query.awaitTermination()
}
}
The method execute implements the logic of the streaming pipeline. There are 6 steps
- Read stream from a set of JSON file located in 'folderPath'' into a data frame, readDF. The schema is inferred from the first JSON record in the constructor
- Apply the transformation on extracted data frame, readDF
- Apply the Spark action on the transformed data frame, transformedDF, on grouped data.
- Use console sink to stream debugging information
- Stream the aggregated data, aggregatedDF into CSV files using a stream writer in Update mode.
- Initiate the streaming process
Extract
The extraction of data consists of loading the JSON data into a partitioned data frame, df through API method, readStream.
df = sparkSession.readStream.schema(mySchema).json(path)
Transform
The transformation, myTransformFunc, convert the data frame using extracted data, readDF and SQL query, sqlStatement, to execute: SELECT age, gender FROM table where age > 18; The result of the query is stored into a temporary view, 'temptable'.
def myTransformFunc(
readDF: DataFrame,
sqlStatement: String
)(implicit sparkSession: SparkSession): DataFrame = {
readDF.createOrReplaceTempView("TempView")
sparkSession.sql(sqlStatement)
}
val myTransform = new STransform(
Seq[String]("age","gender"),
Seq[String]("age > 18"),
myTransformFunc,
"Filter by age"
)The second step is to compute the average age of grouped data as SELECT gender, avg(age) FROM TempView GROUP BY gender;
def aggregatedFunc(inputColumn: Column): Column = {
import org.apache.spark.sql.functions._
avg(inputColumn)
}
val myAggregator = new SAggregator(
new Column("gender"),
new Column("age"),
aggregatedFunc,
"avg_age")
Load
The final task is to write the CSV file sink.
df.writeStream.outputMode(Update())
.foreachBatch{
(df: DataFrame, batchId: Long) =>
df.persist()
df.select('ave_age').write.mode(Overwrite).format("css").save(path)
df.unpersist()
}.trigger(Trigger.ProcessingTime("4 seconds")).start()
The foreachBatch function enables developers to define a specific operation to be applied to the output data from each micro-batch within a streaming query. However, this function cannot be used in continuous processing mode, where foreach would be the suitable alternative.
The mode defines the procedure to update the unbounded result table:
- Append mode (Default) Rows are appended to the result table for query (select, where, map, flatMap, filter, join
- Complete mode: The result table is output after a trigger, required for aggregation.
- Update mode: Only the rows in the results table added since the last trigger event are output to the sink.
Putting all together
SparkStructStreamsFromFile( path, OutputMode.Update(), outputFormat = "csv", outputTable = "avg_age", debug = true, myTransform, myAggregator ).execute()
The output of the streaming pipeline in CSV format is
gender, avg(age)
male,36
female,33
Thank you for reading this article. For more information ...
